1. 5.7 inch LED screen

2. Standard configure with 3.5 MHz abdominal convex array probe.

3. Fast backfat function (moving caliper), measuring backfat quickly and easily.

4. Display mode: B, B+B, 4B, B+M, M;

5. Electronic focus: four-segment electronic focus;

6. Body position markers: ≥18 kinds;

7. Frequency conversion: five-segment frequency conversion function;

8. Image mirroring: rotate the mirror up, down, left and right, and the interface can be flipped in black and white;
9. With image rotation function, the image can be flipped up and down, left and right;

10. Body marks: ≥18 kinds; in addition, there is an annotation function, which is convenient for text and body marks to be marked;

11. Conventional measurement: distance, perimeter, area, volume, angle;

12. Specialist measurement: obstetric measurement of 8 kinds of animals, cardiac measurement, lean meat rate measurement;

13. It has the function of grid ruler and dot ruler, which can quickly read the size of the detection target

14. Character display: gain, frequency, dynamic, date, time;

15. With 256-frame movie playback function, frame-by-frame playback and video playback, frame-by-frame playback can select any image measurement annotation and save functions;

16. Storage: optional 8G memory card, and external U disk storage, you can browse pictures locally, and transfer the built-in pictures to U disk;
17. Dynamic range: 0-135dB;

18. Image processing: gamma correction (0-7), frame correlation (0-3), line correlation (0-5), edge enhancement (0-3), left and right flip (0-1), sixteen kinds of pseudo-color deal with;

19. Blind area: ≤4

20. Maximum display depth: 3.5MHz: 270mm

21. Interface: USB, TF card, VIDEO;

22. Geometric accuracy: horizontal ≤ 5%, vertical ≤ 5%

23. Resolution: lateral ≤2mm, axial ≤1mm

24. Display magnification: 16 display modes;

25. Gain range: 0～100dB;

26. Near field adjustment range: -31~0;
27. Far-field adjustment range: 0~31;

28. It has settings such as time and date, video output, TV format, key tone switch, parameter mode, standby protection, multi-language selection, and custom pregnancy weeks;

29. Battery level indication, U disk indication, prompt information display;

30. Large-capacity lithium battery, imported 18650 standard battery, can work continuously for about 4 hours;

31. Host size: 245x130x44mm (length x width x height);

32. Host weight: 740g;

33. Dual heat dissipation channels, more smooth heat dissipation
